EVC EV Charging Station 22kW

EVC EV Charging Station 22kW

R 7 500,00

Category: Uncategorized

Description
Reviews (0)

Built with durable materials and compliant with IEC standards it delivers fast, reliable three-phase AC charging up to 22kW. Tuya Smart app control for remote monitoring, scheduling, and energy management. Charge current can be set on the app or manually on the unit.

Function	Level 2 AC EV Charging Station
Modes	Plug and charge, App start, RFID start or schedule
Rating	32 A / 22 kW 3-Phase
Voltage	380 – 480 VAC 50/60 Hz
Current adjustment	6 to 32 A
Connectivity	Wi-Fi 2.4 GHz, BT
App	Tuya / Smart Life App
Cable	5 m TPU jacket
Charge plug	IEC 62196-2 Type 2
Display	4.3″ LCD + RGB Indicators
Enclosure	IP65 weatherproof
Standards	IEC 61851 with TUV CE, UKCA, RoHS certification
RCD protection	Type B
Safety	Leakage current protection, over current protection, ground protection, surge protection, O/U voltage protection, O/U frequency protection, temp protection
Controller dimensions	250 x 250 x 90 mm
Material	Polycarbonate
Mass	< 6 kg
Box dimensions	350 x 400 x 220 mm
Operating temp.	-30° to +55° C
Model	VCS-741-22S
Included	Manual, 2 RFID cards, wall bracket, screws, plug and cable holder
