Deye Hybrid Three-phase Inverter 40kWh For High Voltage Batteries

Higher yields / Safe and reliable / Intelligent / Easy to use

The SUN-40K-SG01HP3-EU-BM4 is a brand new three-phase hybrid inverter with a high-voltage battery, providing a safe and reliable system. With a compact design and high power density, this series supports a DC/AC ratio of 1.3, saving on device investment. It supports three-phase unbalanced output, extending application scenarios. Equipped with CAN (x2) BMS and parallel ports, x1 RS485 port for BMS, x1 RS232 port for remote control and x1 DRM port, making the system intelligent and flexible.

It is equipped with an RS485/CAN port for communication with the battery

• Remote switch-off function
• Intelligent Monitoring Platform
• Thanks to the intelligent monitoring platform, the Deye full series inverter products support immediate remote shutdown when an incident occurs. Parameter setting and remote FW update simplify the operation and maintenance of the PV system.
• Unbalanced output to 100%, each phase; max. output to 50% of rated power
• DC pair and AC pair for retrofitting existing solar system
• Maximum. 10 pieces in parallel for on-grid and off-grid operation; supports multiple batteries in parallel
• Maximum. charge/discharge current of 100A
• High-voltage battery, higher efficiency
• 6 time periods for charging/discharging the battery
• Supports energy storage from the diesel generator
• CEI-021 certified with Deye Bos-G batteries and HV Control Box BOS-GBS (4 to 12 batteries in series)
